Detail
Thermal Transfer Desktop Barcode Printer Model TTP – 345, delivers more performance for the price than any other printer in its class. The TTP-345 runs at an impressive 177.8mm per second, printing up to 4 inches wide at 203 dpi resolution. It offers USB 2.0, parallel and serial connectivity. It also incorporates the printer-control language, while supporting TPLE (Translation Printer Language Eltron®) and TPLZ (Translation Printer Language Zebra®). The languages automatically decipher and translate the format of each label as it is sent to the printer. TSPL-EZ™ also features internal scalable True Type fonts (based on the Monotype® font engine), which are typically found only in more expensive printers. It can be mounted with the below Label Winder Model LRW-100 to print Serial No., Data, Logos, Scannable Bar Codes, etc.
SPECIFICATIONS:
|
Media Width |
20 – 112 mm (0.78” – 4.4”) |
|
Media Thickness |
0.06 – 0.19 mm (2.3 – 7.4 mil), max 150 g/m2 |
|
Media Core Diameter |
25.4 – 76.2 mm (1” – 3”) |
|
Label Length |
Min. 10 mm (0.4”) |
|
Resolution |
300 dpi |
|
Print Speed |
2, 3, 4, 5 ips selectable |
|
Max Print Width |
106 mm (4.17”) |
|
Max Print Length |
1,016 mm (40”) |
|
Ribbon Capacity |
300 meters, 1” core |
|
Label Roll Capacity |
127 mm (5”) OD |
|
Interface |
RS-232, Centronics, USB 2.0 (Full Speed mode) |
|
Power Supply: |
100 - 240 Vac, 1 Phase |
|
Speed: |
Up to 1500 Labels / Min. |
