Detail
Semi-Automatic Edge Security Sticker Labeling Model ELM – 100 for applying Security or Flap Closing Sticker labels at Right Angle on Flat boxes / cartons at speeds up to 40 per minute. Just press and hold the box and push it gently to complete the right-angle seal. This is an ideal desktop labeler. Compacted design, it is light and convenient to move. Scope of application: PP tape, PET cloth tape, Glass cloth tape, and so on. Sealing of outer casings of pharmaceuticals, cosmetics, foods, and precision parts.
Additional cost for Ultrasonic Transparent type Label sensing Sensor
SPECIFICATIONS:
|
Product Dimensions (mm) |
L: Any; W:20mm～320mm; H: 10mm～100mm |
|
Label Size: W x L |
L:10mm ～ 24mm; W:15mm ～ 45mm. |
|
Label Material |
Polyester, Polypropylene, Aluminium-foil paper, Synthetic paper |
|
Label Shape |
Circular, Oval, Rectangle, Heart-shaped |
|
Labeling Speed: |
15 – 40 boxes/min |
|
Labeling Accuracy |
± 0.5mm |
|
Roll Dia. Ext. / Int. |
≤ φ120 mm / φ42 - φ75 mm |
|
Power Supply |
220V 50HZ/60HZ, 6W |
|
Machine Size / Weight |
350mm×165mm×220mm(L × W × H) / 10Kg |
